2017 Surly Cross Check
$ 999.00 $ 1,100.00
Fall 2019 Sale! We've got a handful of 2017 Cross Checks left in stock - $100 off regular price. The design on these bikes has barely changed at all over the years - these 2017s are rock solid and excited to find their new homes! We rarely put Surlys on sale so now's your chance...
11/15/19 in stock:
- 42cm Black
- 60cm Mule Mug
- 62cm Mule Mug
Call us at 510-843-7471 for most up-to-date inventory
Frameset
Frame
Surly Cross-Check, Surly 4130 CroMoly steel. Main triangle double-butted. TIG-welded
Fork
Surly Cross-Check, 4130 CroMoly, lugged & brazed. Sloping crown w/threaded eyelets, tapered & butted curved blades w/mid-blade rack eyelets, dual dropout eyelets
Seatpost Clamp
Surly stainless, 30.0mm
Drivetrain
Crankset
Shimano CX50, 36/46t
Bottom Bracket
Shimano 4600
Front Derailleur
Shimano Tiagra 4600
Rear Derailleur
Shimano Deore T610-SGS
Cog or Cassette
Shimano CS-HG50-10, 11-32, 10-speed
Chain
KMC X10
Components
Headset
Cane Creek Custom 5
Brakes
Tektro M730 V-Brake
Brake Levers
Tektro RL520
Shifters
Microshift BS-M10, bar-end shifter
Stem
HL 31.8
Handlebar
Salsa Cowbell 3
Saddle
WTB Volt Sport, steel rails
Seatpost
Kalloy 368 non-offset (42–50cm), Kalloy 342 offset (52–64cm) 27.2 x 300mm
Wheels
Front Hub
Shimano Deore T610, 32h, 100mm, black w/QR
Rear Hub
Shimano Deore T610, 32h, 135mm, black w/QR
Rims
Alex Adventurer 2
Spokes
DT Swiss Champion, 14g
Tires
Surly Knard, 700c x 41mm, 27 tpi
| Frame Size | Stem Length | Stem Angle | Handlebar Width | Crank Length |
|---|---|---|---|---|
| 42cm | 70.0 | 7.0 | 400.0 | 170.0 |
| 46cm | 80.0 | 7.0 | 400.0 | 170.0 |
| 50cm | 80.0 | 7.0 | 400.0 | 170.0 |
| 52cm | 100.0 | 7.0 | 420.0 | 170.0 |
| 54cm | 100.0 | 7.0 | 420.0 | 175.0 |
| 56cm | 100.0 | 7.0 | 440.0 | 175.0 |
| 58cm | 120.0 | 7.0 | 440.0 | 175.0 |
| 60cm | 120.0 | 7.0 | 460.0 | 175.0 |
| 62cm | 120.0 | 7.0 | 460.0 | 175.0 |
| 64cm | 120.0 | 7.0 | 460.0 | 175.0 |
